The Partizan PSW-24 is a CCTV PoE switch featuring 24 PoE ports and 4 regular ports, designed for professional surveillance network installations. This switch delivers a total PoE power budget of 450 watts with per-port power options of 15.4 and 30 watts. The unit offers a switching capacity of 16.8 and supports IEEE 802.3i (10Base-T), 802.3u (100Base-TX), 802.3x (Flow control), and IEEE 802.3af (DTE Power via MDI) standards.
The PSW-24 provides comprehensive connectivity for PoE-powered devices through its 24 dedicated PoE ports, while the 4 regular ports offer additional non-PoE network connections. The switch operates with IEEE 802.3af power delivery compliance, enabling standardized power transmission to compatible network devices.
The unit operates on AC power supply rated at 100-240V and 50/60Hz with a Type C/F European plug. Operating temperature range spans 0 to 40°C with humidity tolerance of 20-95% RH non-condensing, and storage temperature ranges from -30 to 50°C. Dimensions measure 440 x 200 x 45 mm with a weight of 2390 grams. The product includes a 3-year warranty.
Specification
| Gigabit ethernet ports |
4 x 100/1000 M
|
| Gigabit PoE ports |
24 x 100/1000 M
|
| PoE power (per port) |
15.4 W,
30 W
|
| PoE power (total) |
450 W
|
| Switching capacity |
16.8 Gbps
|
| Supported standards |
IEEE 802.3i (10Base-T) ,
IEEE 802.3u (100Base-TX),
IEEE 802.3x (Flow control),
IEEE 802.3af — DTE Power via MDI,
IEEE 802.3af
|
Electrical specification
| AC Plug |
EU (Type C/F)
|
| AC power supply |
100-240 V 50/60 Hz
|
Mechanical specifications
| Dimension |
440 x 200 x 45 mm
|
| Weight |
2390 g
|
Operating conditions
| Humidity range |
20-95% RH (non-condensing)
|
| Operating temperature |
0 - 40 °C
|
| Storage temperature |
-30 - 50 °C
|
