The Partizan NVH-852 is an 8-channel network video recorder from the SH series, designed for surveillance system management. This NVR supports H.264 and H.265 video compression along with G711A audio codec, and features 8 integrated 10/100 PoE ports for direct camera connection.
The recorder supports multiple recording modes at 25 fps across all 8 channels at resolutions up to 8 megapixels. Display output options include VGA and HDMI with resolutions ranging from 1024x768 to 2560x1440, and video splitter modes of 1, 4, 6, 8, and 9 views. Smart analytics capabilities include intrusion detection, line crossing detection, stationary object detection, pedestrian detection, face detection, cross counting, and face recognition. Network functions encompass DDNS, IP Filter, Email, NTP, PPPoE, UPnP, FTP, and RTP/RTSP. The system offers remote access, cloud recording, and PUSH notifications through the Partizan mobile and desktop applications, with web browser support for Chrome, Firefox, and Edge. The interface is available in English, French, German, Italian, Portuguese, Russian, Spanish, and Turkish.
The unit features a metal housing with plastic front panel, measuring 300x227x53mm and weighing 2500g. It operates on 48V DC power with included power supply, consuming up to 1500mA, and functions in temperatures from -40 to 60°C with 20-95% humidity. Storage supports 1 internal HDD up to 10TB. The package includes an optical mouse and power adapter, backed by a 3-year warranty.
Product details
| Model |
NVH-852
|
| Version |
SH v1.0
|
| SKU |
1842
|
| Series |
SH series
|
Encoder
| Maximum cameras |
8 pcs
|
| Recording modes (IP) |
8x8MP@25 fps, 8x5MP@25 fps, 8x2MP@25 fps
|
| Video codec |
H.264,
H.265
|
| Audio codec |
G711A
|
| Two-way audio |
no
|
Graphical user interface
| Display resolution |
2560x1440, 1920x1080, 1440x900, 1280x1024, 1280x720, 1024x768
|
| Video splitter modes |
1,
4,
6,
8,
9
|
| Languages |
English,
French,
German,
Italian,
Portuguese,
Russian,
Spanish,
Turkish
|
Storage
| Internal HDD |
1 x 10 TB
|
| HDD storage (important note) |
For reliable 24/7 operation, it is strongly recommended to use HDDs specifically designed for video surveillance systems. Hard disk drive is not included in the package.
|
Network
| Network interfaces |
RJ-45 (10/100Base-T)
|
| Ethernet PoE ports |
8 x 10/100 M
|
| Network functions |
DDNS,
IP FILTER,
Email,
NTP,
PPPoE,
UPnP,
FTP,
RTP/RTSP
|
| Default IP address |
DHCP
|
| HTTP(s) port |
80
|
| Control port |
9988
|
| RTSP port |
554
|
| RTSP URL |
rtsp://LOGIN:PASSWORD@IP:PORT/rtsp/streaming?channel=1&subtype=0
|
Default credentials
| Default login |
admin
|
| Default password |
admin
|
Software
| Smart analytics |
Intrusion detection,
Line crossing detection,
Stationary object detection,
Pedestrian Detection,
Face detection,
Cross counting,
Face recognition
|
| Smart analytics (important note) |
Smart alarms can only be used with SH-series IP cameras
|
| Cloud abilities |
Remote access,
Cloud recording,
PUSH notifications
|
| Desktop apps |
Partizan,
Setup Tool
|
| Mobile app |
Partizan
|
| Web browsers |
Google Chrome,
Mozilla Firefox,
Edge
|
| Web browser usage (important note) |
Web browser access requires Partizan SurveillancePluginV2 installation for device setup and live view. Available at www.apps.partizan.global
|
External interfaces
| Video output |
VGA,
HDMI
|
| Audio outputs |
1
|
| USB ports |
2 x USB 2.0
|
Mechanical specifications
| Front panel material |
Plastic
|
| Housing material |
Metal
|
| Dimension |
300 x 227 x 53 mm
|
| Weight |
2500 g
|
Power
| DC power source |
48 V
|
| DC consumtion |
1500 mA
|
| DC power supply |
Included
|
Operating conditions
| Humidity range |
20-95% RH (non-condensing)
|
| Operating temperature |
-40 - 60 °C
|
| Storage temperature |
-40 - 60 °C
|
Common
| Package contents |
Optical mouse,
Power adapter
|
| Warranty |
3 years
|
