5Mp PTZ IP camera IPS-230X-IR Starlight SH
Code: 1860Related products
Product detailed description
The Partizan IPS-230X-IR Starlight SH is a PTZ IP camera from the SH series, featuring a 1/2.7" CMOS sensor with 5MP resolution (2592×1944) at 25fps and powerful 33× motorized optical zoom with 4.3-141.9mm focal length. This outdoor-ready surveillance camera delivers exceptional low-light performance with 0.05 lux sensitivity and 150m IR illumination range.
Key features
- ✓150m IR night vision — 10 IR LEDs for extended-range surveillance
- ✓33× optical zoom — motorized lens with 4.3-141.9mm focal length
- ✓Full PTZ control — 360° pan, 100° tilt, up to 200°/s speed
- ✓120dB WDR — enhanced imaging in challenging lighting conditions
- ✓AI smart analytics — LPR, vehicle/pedestrian detection, intrusion alerts, tracking
- ✓H.265/H.264 compression — efficient bandwidth and storage management
- ✓Flexible power options — 24V DC or PoE Class 0 connectivity
- ✓Two-way audio — audio input and output interfaces
Built with IP66-rated weatherproof protection, this camera operates reliably in temperatures from -40°C to 60°C and humidity levels of 20-95% RH. The plastic housing with metal mount weighs 2150g and measures 352×334×207mm. Backed by a 3-year warranty.
Product details
| Model | IPS-230X-IR |
|---|---|
| Version | Starlight SH |
| SKU | 1860 |
| Series | SH series |
Encoder
| Main stream | 2592x1944@25 fps, 2592x1520@25 fps, 2048x1536@25 fps, 2304x1296@25 fps, 1920x1080@25 fps, 1280x960@25 fps, 1280x720@25 fps |
|---|---|
| Sub stream | 1280x720@12 fps, 640x480@12 fps, 320x240@12 fps |
| Mobile stream | 640x480@25 fps, 320x240@25 fps |
| Video codec | H.264, H.265 |
Image sensor
| Sensor | 1/2.7" CMOS |
|---|---|
| Pixel size | 2.0x2.0 μm |
| Day/Night mode | Auto, Color, Black&White |
| Sensitivity | 0.05Lux |
| Dynamic range WDR | 120dB |
| S/N ratio | 50dB |
| Exposure modes | Auto, Manual |
| Exposure range | 1/50 - 1/10000 s |
| Video functions | AES, AGC, AWB, ABF, BLC, OSD, Privacy mask, WDR |
Lens
| Lens type | Spherical |
|---|---|
| Iris | F1.6 - 4.3 |
| Focal length | 4.3 - 141.9 mm |
| Zoom | Motorized |
| Horizontal view | 2 - 59° |
| Vertical view | 1 - 38° |
IR LED
| LED type | IR LED |
|---|---|
| Distance | ≤150 m |
| Number of LEDs | 10pcs |
Network
| Network interfaces | RJ-45 (10/100Base-T) |
|---|---|
| Network functions | DHCP, DNS, DDNS, RTP/RTSP, PPPoE, SMTP, NTP, UPnP, SNMP |
| Default IP address | DHCP |
| HTTP(s) port | 80 |
| Control port | 9988 |
| RTSP port | 554 |
| RTSP URL | rtsp://LOGIN:PASSWORD@IP:PORT/rtsp/streaming?channel=1&subtype=0 |
Default credentials
| Default login | admin |
|---|---|
| Default password | admin |
Software
| Smart analytics | Vechicle detection, Pedestrian detection, Intrusion detection, Line crossing detection, Stationary object detection, Cross counting, Crowd density detection, Queue length detection, License plate detection, License plate recognition, Audio detection, Region entrance, Region exiting, AI schedule, Tracking |
|---|---|
| Smart analytics (important note) | IP camera alarms can only be utilized with Partizan Cloud platform, Partizan mobile application, and Partizan SH series video recorders. |
| Cloud abilities | Remote access, Cloud recording, PUSH notifications |
| Desktop apps | Partizan, Partizan Setup Tool |
| Mobile app | Partizan |
| Web browsers | Google Chrome, Mozilla Firefox, Edge |
| Web browser languages | English, French, German, Italian, Portuguese, Russian, Spanish, Turkish |
| Web browser usage (important note) | Web browser access requires Partizan SurveillancePluginV2 installation for device setup and live view. Available at www.apps.partizan.global |
External interfaces
| Alarm inputs | 1 |
|---|---|
| Alarm outputs | 1 |
| Mic | Audio input |
| Speaker | Audio output |
PTZ
| Pan range | 360° |
|---|---|
| Tilt range | 100° |
| PT speed | min ~ 200 °/s |
Mechanical specifications
| IP rating | IP66 |
|---|---|
| Dimensions | 352 x 334 x 207 mm |
| Weight | 2150g |
| Housing material | Plastic |
| Mount material | Metal |
Power
| DC power source | 24V |
|---|---|
| DC consumption | 2500 mA |
| PoE | PoE Class 0 |
Operating conditions
| Humidity range | 20-95 % RH (non-condensing) |
|---|---|
| Operating temperature | -40 - 60 °C |
| Storage temperature | -40 - 60 °C |
Common
| Package contents | Drill template, Mounting kit |
|---|---|
| Warranty | 3 years |
Additional parameters
| Category: | PTZ |
|---|---|
| Warranty: | 3 years |
| Weight: | 2.1 kg |
| EAN: | 5061099737647 |
| Series: | SH |
| Case type: | PTZ Speed Dome |
| Resolution: | 5Mp |
| Lens Type: | Motorized Varifocal Lens |
| Focus: | 4.3-141.9mm |
| Night vision type: | Starlight (IR) |
| Night vision range: | 150m |
| Software support: | Partizan (PC/Android/iOS), Web interface (IE) |
| Housing material: | Metal |
| Alarm I/O: | 1/1 |
| Audio I/O: | 1/1 |
| Special features: | SD-card support, RTSP, True WDR |
| Smart features: | Human Detection, Face Detection, Face Recognition, Perimeter Intrusion Detection, Line Crossing Detection, Cross Counting, Stationary Object Detection, Attendance Control, Attribute Detection, Heat Map, Crowd Density Detection, Queue Length Detection, License Plate Detection, License Plate Recognition, Sound Detection, Vehicle Detection |
| The item has been sold out… | |
