The Partizan NVH-452 POE SH is a network video recorder from the SH series, designed to support up to 4 IP cameras with 8 integrated 10/100 Ethernet PoE ports for simplified camera connectivity. This CCTV NVR supports H.264 and H.265 video compression along with G711A and G711U audio codecs.
The recorder offers multiple recording configurations at 25 fps across various resolutions including 8MP, 5MP, and 2MP streams. Display output is available through both VGA and HDMI interfaces with resolutions up to 2560x1440, featuring 1-channel and 4-channel video splitter modes. Smart analytics capabilities include intrusion detection, line crossing detection, stationary object detection, cross counting, face recognition, face detection, and pedestrian detection. Cloud functionality provides remote access, cloud recording, and PUSH notifications, with support for Partizan desktop and mobile applications. Network features include IP FILTER, DDNS, Email, NTP, PPPoE, UPnP, FTP, and RTP/RTSP protocols. The interface supports eight languages including English, German, French, Spanish, Russian, Italian, Portuguese, and Turkish.
The unit features a metal housing with plastic front panel, measuring 300x227x53mm and weighing 2500g. It accommodates 1 internal HDD up to 10TB, operates on 48V DC power with 1500mA consumption, and functions within -40 to 60°C temperature range at 20-95% RH. The package includes an optical mouse and power adapter, backed by a 3-year warranty.
Product details
| Model |
NVH-452
|
| Version |
POE SH
|
| SKU |
1864
|
| Series |
SH series
|
Encoder
| Maximum cameras |
4 pcs
|
| Recording modes (IP) |
4x8MP@25 fps, 4x5MP@25 fps, 4x2MP@25 fps
|
| Video codec |
H.264,
H.265
|
| Audio codec |
G711A,
G711U
|
| Two-way audio |
no
|
Graphical user interface
| Display resolution |
2560x1440, 1920x1080, 1440x900, 1280x1024, 1280x1024, 1280x720, 1024x768
|
| Video splitter modes |
1,
4
|
| Languages |
English,
French,
German,
Italian,
Portuguese,
Russian,
Spanish,
Turkish
|
Storage
| Internal HDD |
1 x 10 TB
|
| HDD storage (important note) |
For reliable 24/7 operation, it is strongly recommended to use HDDs specifically designed for video surveillance systems. Hard disk drive is not included in the package.
|
Network
| Network interfaces |
RJ-45 (10/100Base-T)
|
| Ethernet PoE ports |
8 x 10/100 M
|
| Network functions |
IP FILTER,
DDNS,
Email,
NTP,
PPPoE,
UPnP,
FTP,
RTP/RTSP
|
| Default IP address |
DHCP
|
| HTTP(s) port |
80
|
| Control port |
9988
|
| RTSP port |
554
|
| RTSP URL |
rtsp://LOGIN:PASSWORD@IP:PORT/rtsp/streaming?channel=1&subtype=0
|
Default credentials
| Default login |
admin
|
| Default password |
admin
|
Software
| Smart analytics |
Intrusion detection,
Line crossing detection,
Stationary object detection,
Cross counting,
Face recognition,
Pedestrian Detection,
Face detection
|
| Smart analytics (important note) |
Smart alarms can only be used with SH-series IP cameras
|
| Cloud abilities |
Remote access,
Cloud recording,
PUSH notifications
|
| Desktop apps |
Partizan,
Setup Tool
|
| Mobile app |
Partizan
|
| Web browsers |
Google Chrome,
Mozilla Firefox,
Edge
|
| Web browser usage (important note) |
Web browser access requires Partizan SurveillancePluginV2 installation for device setup and live view. Available at www.apps.partizan.global
|
External interfaces
| Video output |
VGA,
HDMI
|
| Audio outputs |
1
|
| USB ports |
2 x USB 2.0
|
Mechanical specifications
| Front panel material |
Plastic
|
| Housing material |
Metal
|
| Dimension |
300 x 227 x 53 mm
|
| Weight |
2500 g
|
Power
| DC power source |
48 V
|
| DC consumtion |
1500 mA
|
| DC power supply |
Included
|
Operating conditions
| Humidity range |
20-95% RH (non-condensing)
|
| Operating temperature |
-40 - 60 °C
|
| Storage temperature |
-40 - 60 °C
|
Common
| Package contents |
Optical mouse,
Power adapter
|
| Warranty |
3 years
|
