The Partizan NVH-3252 is a 32-channel network video recorder from the SH series, designed for professional CCTV surveillance systems. This NVR supports H.264 and H.265 video codecs along with G711A and G711U audio codecs, and features two-way audio capability.
The recorder offers multiple recording modes at 25 fps across 32 channels at 8MP, 5MP, and 2MP resolutions. It provides extensive video splitter modes including 1, 4, 6, 8, 9, 10, 13, 14, 16, 17, 19, 22, 25, 32, and 36 view options, with display resolutions up to 1920x1080. Smart analytics features include intrusion detection, line crossing detection, stationary object detection, pedestrian detection, face detection, cross counting, and face recognition. The unit supports cloud abilities including remote access, cloud recording, and PUSH notifications, with access via Partizan mobile and desktop apps, or web browsers including Google Chrome, Mozilla Firefox, and Edge.
Storage accommodates 4 internal HDDs up to 10TB each and 1 external HDD up to 10TB. The unit features RJ-45 Gigabit Ethernet, VGA and dual HDMI video outputs, 1 audio input, and 1 audio output. Operating on 12V DC with included power supply at 5000mA consumption, the metal-housed recorder with plastic front panel measures 378x326x66mm and weighs 4000g. Operating temperature ranges from -40 to 60°C with 20-95% RH humidity tolerance. Package includes optical mouse and power adapter with 3-year warranty.
Product details
| Model |
NVH-3252
|
| Version |
SH v1.0
|
| SKU |
2557
|
| Series |
SH series
|
Encoder
| Maximum cameras |
32 pcs
|
| Recording modes (IP) |
32x8MP@25 fps, 32x5MP@25 fps, 32x2MP@25 fps
|
| Video codec |
H.264,
H.265
|
| Audio codec |
G711A,
G711U
|
| Two-way audio |
yes
|
Graphical user interface
| Display resolution |
1920x1080, 1440x900, 1280x1024, 1280x720, 1024x768
|
| Video splitter modes |
1,
4,
6,
8,
10,
9,
13,
14,
16,
22,
32,
25,
36,
17,
19
|
Storage
| Internal HDD |
4 x 10 TB
|
| External HDD (eSATA) |
1 x 10 TB
|
| HDD storage (important note) |
For reliable 24/7 operation, it is strongly recommended to use HDDs specifically designed for video surveillance systems. Hard disk drive is not included in the package.
|
Network
| Network interfaces |
RJ-45 (10/100/1000Base-T)
|
| Network functions |
DDNS,
IP FILTER,
Email,
NTP,
PPPoE,
UPnP,
FTP,
RTP/RTSP
|
| Default IP address |
DHCP
|
| HTTP(s) port |
80
|
| Control port |
9988
|
| RTSP port |
554
|
| RTSP URL |
rtsp://LOGIN:PASSWORD@IP:PORT/rtsp/streaming?channel=1&subtype=0
|
Default credentials
| Default login |
admin
|
| Default password |
admin
|
Software
| Smart analytics |
Intrusion detection,
Line crossing detection,
Stationary object detection,
Pedestrian Detection,
Face detection,
Cross counting,
Face recognition
|
| Smart analytics (important note) |
Smart alarms can only be used with SH-series IP cameras
|
| Cloud abilities |
Remote access,
Cloud recording,
PUSH notifications
|
| Desktop apps |
Partizan,
Setup Tool
|
| Mobile app |
Partizan
|
| Web browsers |
Google Chrome,
Mozilla Firefox,
Edge
|
| Web browser usage (important note) |
Web browser access requires Partizan SurveillancePluginV2 installation for device setup and live view. Available at www.apps.partizan.global
|
External interfaces
| Video output |
VGA,
2 x HDMI
|
| Audio inputs |
1
|
| Audio outputs |
1
|
| USB ports |
2 x USB 2.0, 1 x USB 3.0
|
Mechanical specifications
| Front panel material |
Plastic
|
| Housing material |
Metal
|
| Dimension |
378 x 326 x 66 mm
|
| Weight |
4000 g
|
Power
| DC power source |
12 V
|
| DC consumtion |
5000 mA
|
| DC power supply |
Included
|
Operating conditions
| Humidity range |
20-95% RH (non-condensing)
|
| Operating temperature |
-40 - 60 °C
|
| Storage temperature |
-40 - 60 °C
|
Common
| Package contents |
Optical mouse,
Power adapter
|
| Warranty |
3 years
|
